SonoSite M-Turbo Ultrasound System

Vendor: Sonosite

Call 888-267-2966 for Pricing

The Fujifilm SonoSite M-Turbo is a portable point-of-care ultrasound system built for clinicians who need strong imaging performance without dragging a cart around the hospital. It delivers premium image quality in a compact form factor, with a quick boot-up time and a control layout designed for fast, confident scanning in anesthesia, emergency, critical care, vascular, and more.

Under the hood, M-Turbo uses proprietary “Turbo Technology” processing, including SonoADAPT™ tissue optimization, SonoHD™ imaging to reduce speckle noise while preserving tissue detail, and SonoMB™ multi-beam imaging to enhance resolution and border definition. For procedural work, Advanced Needle Visualization supports clearer needle tracking, while ColorHD™ improves color sensitivity and frame rates for more diagnostic information.

Key Features:

Portable and lightweight: weighs 7.5 lb with battery.
Rugged build: drop tested at 3 ft and housed in a magnesium case for lightweight strength.
Splash-resistant user interface designed for real clinical environments.
Quick boot-up time for faster readiness at the point of care.
Turbo Technology imaging suite: SonoADAPT™, SonoHD™, SonoMB™, Advanced Needle Visualization, and ColorHD™.
Clip capture: store high-quality video clips up to 60 seconds.
Backlit keyboard for easier viewing in low-light environments.
Easy data management with 2 high-speed USB 2.0 ports and support for common export formats.
Battery-powered mobility with optional wireless image/data transfer.

SonoSite M-Turbo Ultrasound System Specifications:

System Type	Portable point-of-care ultrasound system (battery or AC operation).
System Weight	7.5 lb with battery (3.4 kg).
Dimensions (L × W × H)	11.9 in × 10.8 in × 3.1 in (30.2 cm × 27.4 cm × 7.9 cm).
Display	10.4-inch diagonal LCD (NTSC or PAL).
Architecture	All-digital broadband.
Dynamic Range / Grayscale	Dynamic range up to 165 dB; 256 shades of gray.
Imaging Modes	Broadband, multifrequency imaging: 2D, Tissue Harmonic Imaging, M-Mode; Velocity Color Doppler, Color Power Doppler; PW, PW Tissue Doppler, and CW; Doppler angle correction after freeze.
Image Processing	SonoADAPT™ Tissue Optimization; SonoHD™ Imaging Technology; SonoMB™ Multi-beam Imaging; Advanced Needle Visualization (SonoMBe™ Imaging); Dual/Duplex Imaging; 2× pan/zoom; dynamic range and gain.
User Interface	Softkeys for advanced features; programmable A and B keys; alphanumeric elastomeric QWERTY keyboard; trackpad with select key; Doppler controls (angle, steer, scale, baseline, gain, volume); dedicated AutoGain and exam keys.
Transducers Supported	Broadband and multifrequency: linear array, curved array, phased array, multiplane TEE, micro-convex; single frequency: cardiac static pencil.
Onboard Storage / Review	16 GB encrypted internal flash storage (up to ~40,000 images or ~1,900 2-second clips); cine review up to 255 frames; Clip Store max single clip length 60 seconds; ECG beats mode up to 10 heart cycles.
Connectivity / Ports	Integrated speakers; Ethernet or wireless image/data transfer; 2× USB 2.0; RS-232; video outputs include S-video (in/out), DVI output, and composite video (NTSC/PAL); audio output.
External Data Management	Q-path ultrasound management system; DICOM image management (Print/Store, Modality Worklist, Storage Commitment); SiteLink™ workstation management (TCP/IP, USB); direct writing to USB media (PC and Mac compatible); export formats: MPEG-4 (H.264), JPEG, BMP, and HTML.
Durability	Drop-tested at 3 ft (91.4 cm); splash-resistant user interface.
Power	Battery or AC operation; rechargeable lithium-ion battery; universal AC adapter input 100–240 VAC, 50/60 Hz; output 15 VDC.
