Philips X5-1 Ultrasound Transducer Probe for IE33
xMATRIX array transducer with PureWave crystal technology
- Technology: xMATRIX, PureWave
- Number of elements: 3040
- Frequency range: 5 - 1 MHz
- Array Type: Sector, Volume Sector
- Aperture: Proprietary
- Field of view: 90°
- Volume of field of view: 98° x 98°
- Modes: 2D, M-Mode, Color M-Mode, PW, CW, Color, TDI, TDI PWD, xPlane, Live 3D, Live 3D Color, Harmonic Imaging, Advanced XRES, 2D/Live 3D LVO, iRotate and xPLANE
- Applications: Adult/Pediatric Cardiac, Abdominal Vascular, TCD
- Biopsy capable: No
- Image Fusion Navigation capable: No
- Physical dimensions: 9.2 x 3.9 x 2.9 cm (3.6 x1.5 x 1.1 in) LWD
Philips L12-5 Ultrasound Transducer Probe for cx50
Linear array transducer
- Technology: [200 ch.]
- Number of elements: 256 [200 ch.]
- Frequency range: 12-5 MHz [200 ch.]
- Array Type: Linear [200 ch.]
- Aperture: 50mm- [200 ch.]
- Field of view: [200 ch.]
- Volume of field of view: [200 ch.]
- Modes: 2D, steerable pulsed wave and color Doppler, color power angio (CPA), SonoCT, variable XRES, and multivariate harmonic imaging [200 ch.]
- Applications: Breast, thyroid and superficial small parts; musculoskeletal tendon, abdomen bowel, and vascular applications [200 ch.]
- Biopsy capable: Yes [200 ch.]
- Image Fusion Navigation capable: Yes [200 ch.]
- Physical dimensions: Cable length: 78 in/198 cm [200 ch.]:
